Specs:

Engine:

• Block pressure tested and magnafluxed
• Block cleaned
• Block resurfaced
• Main bearing tunnel align honed
• Connecting rods honed
• Crankshaft cleaned and polished
• Cylinders bored out and honed (typically .020 over)
• New pistons
• Oil pump rebuilt
• New King main bearings
• New King rod bearings
• New thrust washers
• New freeze plugs
• New timing chain
• New timing chain vibration pad
• New rear main seal
• Cam polished
• Cam rollers polished
• New 8:1 head modified for unleaded gas
• Hardened exhaust valve seats
• Hardened valves
• New OEM Series III valve guides
• New OEM valve springs
• New OEM valve seals
• New OEM valve retainers and keys
• Pertronix electronic ignition
• New OEM rocker shaft
• New OEM Series III pushrods
• New water pump
• New motor mounts
• New alternator mount
• New alternator
• New OEM fan belt
• New spark plug wires
• New Bosch spark plugs
• Spin on oil filter conversion
• High torque starter
• All engine parts refinished
• Engine block and head painted in high heat green paint
• All aluminum parts sandblasted and finished in high heat clear
• New OEM oil fill cap/ breather
• New OEM valve cover breather
• New OEM front crank seal
• New crank pulley

Fuel System:

• Webber Carburetor
• Facet electric fuel pump
• New stainless steel fuel tank
• New throttle return spring
• Throttle linkage rebuilt and refinished
• New fuel tank to body foam seal
• NOS fuel filler hose
• New OEM fuel tank bushings and mounting hardware
• New fuel cap seal
• New fuel filter
• NOS air cleaner hose
• Air cleaner wire mesh cleaned and housing repainted

Exhaust System:

• New exhaust manifold
• New exhaust hangers
• New exhaust system

Transmission and Transfer Case:

• Rebuilt 5 speed transmission
• Rebuilt transfer case
• Steel transfer case pan refinished
• Extended transmission breather
• New 5 speed shift knob
• New AP clutch and pressure plate
• New NSK throwout bearing
• Flywheel machined
• New clutch fork
• New clutch push rod
• New Delphi clutch slave cylinder
• New TRW clutch hose
• New clutch steel lines
• New OEM clutch master cylinder
• New clutch pedal return spring
• Original red and yellow shift knobs polished
• New transmission mounts
• New speedometer cable

Cooling and Heating:

• Aluminum 4 core radiator
• NOS fan shroud
• New OEM radiator hoses
• New stainless steel hose clamps
• New thermostat
• New radiator cap
• New coolant overflow bottle
• Heater delete

Frame:

• New galvanized frame
• New bump stops
• New galvanized bumper
• New stainless bumper bolts
• Rear grab handles galvanized

Axles:

• Rebuilt front differential
• Rebuilt rear differential
• Original rear half shafts
• New drive flange caps
• Front drive flanges repainted
• Axle housings sandblasted and painted chassis black
• New front Hardy Spicer driveshaft
• New rear Tom Wood double cardan driveshaft
• New driveshaft hardware
• New OEM front axle housing seals
• New extended axle breathers
• Original swivel balls cleaned and polished
• New swivel pins and bushings
• New swivel bearings
• New OEM swivel seals
• Swivels shimmed to correct preload
• Rebuilt front half shafts
• New NTN wheel bearings
• New OEM hub seals
• New OEM hub seal races

Steering

• Steering wheel restored
• Steering box rebuilt
• New Lemforder tie rod ends
• New Series III track rod
• New Series III drag link
• New Series III relay rod
• New tie rod end clamps
• Grade 8 tie rod clamp hardware
• New steering relay
• Steering arms refinished
• Grade 8 steering arm hardware

Brakes

• New Series III power brake pedal box
• New Series III brake booster
• New Ferodo Defender master cylinder
• Forbyn Brothers four wheel disc brake conversion
• New AP front Defender calipers
• New Ferodo front brake pads
• New front rotors
• New Forbyn Bros. front brake hoses
• New AP rear Defender calipers
• New Ferodo rear brake pads
• New rear rotors
• New TRW rear brake hose
• New Series III brake lines and fittings
• Rebuilt parking brake assembly
• Rebuilt and refinished parking brake lever and linkage
• New polished aluminum parking brake button
• New parking brake pivot

Suspension

• New GME parabolic leaf springs
• New Old Man Emu gas shocks
• Heavy duty axle U-bolts
• New shackles
• New shackle bolts and nuts
• Galvanized rear spring mounting plates
• Galvanized extended front spring mounting plates
• Galvanized rear brake line retainer plates

Body

• All body panels completely disassembled and sanded to bare aluminum
• All dents hammer and dollied
• All extra holes in body panels welded
• All cracks in body panels welded
• No door tops supplied
• New bulkhead
• Grille sandblasted and rust repaired
• New OEM lower doors
• All body panels primed and painted on both sides in single stage paint
• Paintwork done to OEM standards
• Body fit and finish to OEM standands
• All cappings galvanized
• Hood frame galvanized
• Hood mounted spare tire hold down galvanized
• Hood hinges galvanized
• Windshield frame galvanized
• Door sills galvanized
• Fender stiffeners galvanized
• Aluminum under seat tool box
• Fuel filler surround galvanized
• Grille holders galvanized
• Under body supports galvanized
• Door jamb stiffeners galvanized
• Door check straps galvanized
• New OEM Defender vent flap seals
• New OEM door weatherstripping
• New OEM bulkhead to windshield frame seal
• New floor hardware
• Hood prop refinished
• New windshield glass
• Windshield retainer strips refinished
• Original door latches and strikers
• Door hinges rebuilt with new brass pivots
• Correct type aluminum hammer rivets and pop rivets
• New zinc plated bolts, nuts, washers and screws used on inside of vehicle
• New stainless steel bolts and screws used on exterior of vehicle
• New hood to grille cloth buffer strip
• Hood latch restored
• New fender mounted mirrors
• Front and rear Land Rover badges refinished

Interior:

• New Exmoor Trim black vinyl seats
• New leather seat retaining straps
• Bulldog catches to retain seat bases
• New Exmoor Trim front rubber floor mats
• New original type load bay rubber mat
• New retractable lap belts
• Front seat mounts galvanized
• Bulkhead diaphragm galvanized
• 4x4 plunger plate galvanized
• Steering column seal retainer galvanized
• New steering column seal
• Windshield hold downs galvanized and rebuilt
• Vent flap levers refinished
• Door pulls refinished
• Seat box turnbuckles and hasps refinished
• New rearview mirror
• New OEM gas pedal rubber pad
• NOS high-low lever boot
• New OEM parking brake boot
• No sound deadening under seat box and transmission tunnel

Soft Top Specific:

• No soft top
• No rear seats
• Stainless steel tailgate latches
• New OEM tailgate weatherstripping
• Tailgate hardware galvanized
• New galvanized tailgate chains
• Tailgate chain mounts galvanized

Electrical and Wipers

• New cloth covered body wiring harness
• New cloth covered engine wiring harness
• New cloth covered frame wiring harness
• New fuse box
• New wiring harness clips
• New headlight pigtails
• New headlights
• New Wipac plastic headlight buckets
• New parking lights and turn signals
• New brake lights
• New license plate light
• New 2 gauge battery cables
• New horn
• New battery
• Horn button restored and painted in wrinkle black
• New horn contact
• New Lucas wiper motor
• New stainless steel wiper arms and blades
• Original temperature gauge and fuel gauge
• New OEM Late IIA coolant temperature sending unit
• New OEM Late IIA fuel level sending unit
• Original speedometer rebuilt
• Odometer returned to 0
• New semiconducter voltage stabilizer
• Turn signal switch restored and refinished
• New keyed ignition switch
• New brake light switch
• New coil
• GM hig
• low beam switch
• New Lucas dash switches
• New red and black dash power sockets
• Spare key

Tires and Wheels

• Five new Defender 16” x 5.5” (Series type) wheels for tubeless tires
• Wheels painted in Limestone
• Five new Michelin XZL 7.50 16 tires
• New valve stems
• New lug nuts
• Lug wrench and hydraulic bottle jack mounted under driver’s seat

Paperwork

• *Current registration
• *Bill of sale
• *Heritage Certificate
• NAO specific owner’s manual
• Three month warranty
• Likely completion date: July 2025

$97,500
